UV-3600i Plus

UV-3600i Plus 紫外/可見光-近紅外光分光光譜儀 (UV-Vis-NIR)

UV-3600i Plus 紫外光-可見光-近紅外光分光光譜儀具有雙分光器 (Double Monochromator) 的設計，標配覆蓋紫外光-可見光-近紅外光區的三檢測器，保證全波長檢測的靈敏度。豐富可選搭的附件可以滿足各類樣品的測試。除了硬體之外，更搭載全新易用且多功能的 LabSolutions UV-Vis 軟體。

特色

對應液體、固體樣品的各種應用

・獨家的 Pass/Fail 自動判斷功能讓品質管制工作更加輕鬆。
・量測分析中即時將數據自動匯出至 Excel 等軟體，並利用巨集 (Macro) 自動取得想要的數值。
三檢測器設計，帶來更高的靈敏度與低雜訊

・紫外光與可見光區使用光電倍增管 (PMT)。
・近紅外光區以 InGaAs 與 PbS 偵測器涵蓋偵測。大幅降低雜訊。
・積分球與大型樣品室等附件亦採用三檢測器設計，提高固體樣品分析靈敏度。
高解析度、超低迷光、更廣的波長範圍

・高解析度 (最高 0.1 nm)。
・超低迷光 (迷光 0.00005% 以下 @340 nm)。
・量測範圍可達185~3300 nm (標準樣品室)。

更多詳情
